Mini8 — Tiny 8-bit Fantasy VM (ASM + MiniBASIC)

Mini8 is a compact 8-bit fantasy virtual machine — all-in-one:
VM + assembler + MiniBASIC + disassembler + self-tests in a single executable.
Perfect for making tiny retro-style programs, learning ASM, or experimenting in game jams.

 Features

• 4 KiB memory (0x0000..0x0FFF) with dedicated stack (0x0C00..0x0FFF).

• Memory-mapped I/O:
  IO_OUT=0x0FF0 (print char), IO_IN=0x0FF1, IO_READY=0x0FF2, IO_RNG=0x0FF3 (8-bit LFSR RNG).

• Compact ISA: 1/2/3-byte opcodes, absolute & relative branches (JR*), shifts/rotates, logic, CALL/RET, PSH/POP.

• Built-in tools: assembler (--asm), MiniBASIC compiler (--basic), disassembler (--disasm), self-tests (--selftest).

• Debug options: tracing (--trace, --trace-pre, --trace-both), single-step (--step), breakpoints (--bp), memory dump (--dump), instruction limit (--limit), clock speed (--mhz, --no-throttle).

• Cross-platform: Windows ( _kbhit() / _getch() ) and POSIX (non-blocking select()).

 Build & Run

Assemble (ASM → ROM)

mini8 --asm source.asm -o prog.rom mini8 prog.rom

Compile (MiniBASIC → ROM)

mini8 --basic source.bas -o prog.rom mini8 prog.rom

Disassemble

mini8 --disasm prog.rom > prog.lst

Run self-tests

mini8 --selftest

 Tiny Examples

Hello (ASM)

ORG 0 LDAI 'H' STA 0x0FF0   ; IO_OUT : prints 'H' LDAI 10      ; newline STA 0x0FF0 HLT

Keyboard input (non-blocking)

ORG 0 LOOP: LDA 0x0FF2    ; IO_READY ?       CMPI 0       JREQ LOOP       LDA 0x0FF1    ; IO_IN       STA 0x0FF0    ; echo char       HLT

Random byte (deterministic with seed)

ORG 0 LDA 0x0FF3   ; IO_RNG STA 0x0FF0 HLT

mini8 --seed 123 rng.rom

 Debugging

• Trace: --trace, --trace-pre, --trace-both

• Step: --step (keys: s=step, c=continue, r=regs, q=quit)

• Breakpoints: --bp 0x0123 --bp 0x0200

• Hexdump: --dump or --dump-from 0x0200 --dump-len 128

• Speed: --mhz 1.0 or --no-throttle

• Instruction cap: --limit 2000

 Download Includes

• Mini8 executable (VM + tools)

• Example ASM/MiniBASIC programs (optional)

• Quickstart guides (FR/EN)

 License

Proprietary — All rights reserved. No copying, modification, or redistribution without explicit written permission.
